china shenzhen huanan hengtai industrial co.,ltd sale lch-10tf it has a very high response speed and can react to load changes in a very short time. this rapid response capability enables sensors to play a key role in real-time monitoring and control systems, ensuring the stability and safety of equipment operation.
inquiry for quotation→e-mail:sales@hnhtsz.com
【support services】
warranty period: 12 months
provide sensor technology support and selection recommendation
【kyowa electronic compression load cell lch-10tf information】
note: the following information is for reference, please refer to kyowa electronic version
kyowa electronic compression load cell lch-10tf datasheet download：
kyowa electronic compression load cell lch-10tf features：
nonlinearity: ±0.02%ro or less
lag: ±0.02%ro or less
repeatability: 0.02%ro or less
rated output: 2mv/v (4000×10-6 variable) ±0.1%
allowable operating temperature range: 35~80℃
temperature compensation range: -10-60℃
zero temperature effect: ±0.0015%ro/℃ or less
output temperature effect: ±0.001%ro/℃ or less
maximum excitation voltage: 20v ac or dc
recommended excitation voltage: 1-10v ac or dc
input resistance: 350ω±0.5%
output resistance: 350ω±0.5%
cable: 0.5mm2, 6-core shielded neoprene armored cable 5m, outer diameter 9.5mm, front end crimping terminal (m4)(shielded cable is not connected to the host)
safe overload: 200%
protection level: ip67 (iec 60529)
kyowa electronic compression load cell lch-10tf dimension：
kyowa electronic compression load cell lch-10tf series models：
lch-10tf
lch-10tf,lch-20tf
